Value of two-dimensional shear wave elastography in the typing of liver Cystic echinococcosis

doi:10.3877/cma.j.issn.1674-1358.2025.01.008

Abstract

Abstract:

Objective

To investigate the value of two-dimensional shear wave elastography (2D-SWE)in the typing of liver Cystic echinococcosis (CE).

Methods

Total of 91 patients with liver CE were admitted to the Fourth People’s Hospital of Qinghai Province from July 2018 to July 2023.Ultrasound, 2D-SWE, CT or MRI examinations were performed on each patient.As 2D-SWE had almost zero shear wave propagation speed in cystic lesions, 41 cases of CE1 and CE2 type were excluded.Total of 50 cases of CE3-CE5 type with solid components were enrolled as study subjects.According to the CT/MRI results, the patients were divided into CE3 group(15 cases), CE4 group (19 cases) and CE5 group (16 cases).The statistical data (age, left and right diameter of lesion,anterior and posterior diameter of lesion, CE hardness value, surrounding liver hardness value) of overall comparison among the three groups were analyzed by One-way analysis of variance, while pairwise comparison in each group were analyzed by LSD-t test.Counting data (sex, number of lesions and location of lesions) were obtained using Pearson Chi-square test or Fisher’s exact probability method, the correlation analysis was conducted using Spearman rank correlation analysis.The diagnostic capability of the correlation between CE classiflcation and CE hardness value was evaluated by receiver operating characteristic curve (ROC) and area under ROC curve (AUC).

Results

The average hardness values of CE3, CE4 and CE5 were (15.77 ± 5.83) kPa, (34.15 ± 9.28) kPa and (50.80 ± 13.73)kPa, respectively.The correlation analysis results showed that CE classiflcation was positively correlated with the average hardness value of CE (r = 0.821, P ＜ 0.001).The CE hardness values among patients in CE3 group, CE4 group and CE5 group were signiflcantly different (F = 45.991, P ＜ 0.001), while the pairwise comparison results between the CE hardness values showed that the differences were statistically signiflcant (CE3 group vs.CE4 group:t =-5.236, P ＜ 0.001, CE3 group vs.CE5 group: t =-9.590, P ＜ 0.001, CE4 group vs.CE5 group: t =-4.828,P ＜ 0.001).The AUC of 2D-SWE for diagnosis type of CE3 and CE4 was 0.941 (95%CI: 0.867-1.000, P ＜ 0.001),with the cut-off value of 19.5 kPa, the sensitivity and speciflcity of 2D-SWE were 94.7% and 73.3%, respectively.The AUC of 2D-SWE for diagnosis type of CE4 and CE5 was 0.826 (95%CI: 0.684-0.967, P ＜ 0.001), with the cutoff value of 47.5 kPa, the sensitivity and speciflcity of 2D-SWE were 62.5% and 89.5%, respectively.

Conclusions

2D-SWE is a safe, economical, non-invasive, rapid, and visualization imaging method, which quantitatively assesses the biomechanical characteristics of liver CE.It serves as an excellent detection tool for typing CE3, CE4 and CE5.Furthermore, the 2D-SWE color elastic map provides real-time display of the distribution of softness and hardness within the CE lesion area.This information can serve as a valuable reference for selecting appropriate mode of operation and surgical instrument.

Key words: Two-dimensional shear-wave elastography, Liver cystic echinococcosiss, Quantitative, Classiflcation

Zhenming Yuan, Jianying Guo, Yuhua Pang, Jinhuan Wang, Dancairang Yang, Guoying Yu. Value of two-dimensional shear wave elastography in the typing of liver Cystic echinococcosis[J]. Chinese Journal of Experimental and Clinical Infectious Diseases(Electronic Edition), 2025, 19(01): 44-51.

/ / Recommend

Add to citation manager EndNote|Ris|BibTeX

URL: https://zhsyhlcgrbzz.cma-cmc.com.cn/EN/10.3877/cma.j.issn.1674-1358.2025.01.008

https://zhsyhlcgrbzz.cma-cmc.com.cn/EN/Y2025/V19/I01/44

Figures/Tables 7

指标	CE3型组（15例）	CE4型组（19例）	CE5型组（16例）	统计量	P值
年龄（ $\overset{ˉ}{x}$ ± s，岁）	41.73 ± 12.59	44.29 ± 16.66	52.93 ± 14.57	F = 2.378	0.105
性别［例（%）］				χ ²= 0.398	0.819^a
男	8（53.33）	12（63.16）	10（62.50）
女	7（56.66）	7（36.84）	6（37.5）
病灶数目［例（%）］				—	0.562^b
单个	12（80.00）	17（89.47）	15（93.75）
≥ 2	3（20.00）	2（10.53）	1（6.25）
病灶部位［例（%）］				—	0.976^b
左叶	3（20.00）	5（26.32）	5（31.25）
右叶	10（66.67）	12（63.15）	10（62.50）
左右叶	2（13.33）	2（10.53）	1（6.25）
病灶左右径（ $\overset{ˉ}{x}$ ± s，mm）	82.92 ± 36.59	57.40 ± 14.27	63.00 ± 29.03	F = 3.092	0.057
病灶前后径（ $\overset{ˉ}{x}$ ± s，mm）	62.17 ± 21.93	44.80 ± 8.39	54.40 ± 26.69	F = 2.453	0.099
CE硬度值（ $\overset{ˉ}{x}$ ± s，kPa）	15.77 ± 5.83	34.15 ± 9.28	50.80 ± 13.73	F = 45.991	＜ 0.001
周围肝脏硬度值（ $\overset{ˉ}{x}$ ± s，kPa）	7.42 ± 1.12	11.04 ± 7.89	9.25 ± 4.98	F = 1.160	0.326

指标	CE3型组（15例）	CE4型组（19例）	CE5型组（16例）	统计量	P值
年龄（ $\overset{ˉ}{x}$ ± s，岁）	41.73 ± 12.59	44.29 ± 16.66	52.93 ± 14.57	F = 2.378	0.105
性别［例（%）］				χ ²= 0.398	0.819^a
男	8（53.33）	12（63.16）	10（62.50）
女	7（56.66）	7（36.84）	6（37.5）
病灶数目［例（%）］				—	0.562^b
单个	12（80.00）	17（89.47）	15（93.75）
≥ 2	3（20.00）	2（10.53）	1（6.25）
病灶部位［例（%）］				—	0.976^b
左叶	3（20.00）	5（26.32）	5（31.25）
右叶	10（66.67）	12（63.15）	10（62.50）
左右叶	2（13.33）	2（10.53）	1（6.25）
病灶左右径（ $\overset{ˉ}{x}$ ± s，mm）	82.92 ± 36.59	57.40 ± 14.27	63.00 ± 29.03	F = 3.092	0.057
病灶前后径（ $\overset{ˉ}{x}$ ± s，mm）	62.17 ± 21.93	44.80 ± 8.39	54.40 ± 26.69	F = 2.453	0.099
CE硬度值（ $\overset{ˉ}{x}$ ± s，kPa）	15.77 ± 5.83	34.15 ± 9.28	50.80 ± 13.73	F = 45.991	＜ 0.001
周围肝脏硬度值（ $\overset{ˉ}{x}$ ± s，kPa）	7.42 ± 1.12	11.04 ± 7.89	9.25 ± 4.98	F = 1.160	0.326
